GIAC performance software for the seat Leon ® ( MK2 2005 - 2011 )

2.0 TDI 140ps


Engine
Controllers


Info
GIAC Stage 1 Plus adds horsepower, torque and more throttle response throughout the power band. This calibration is compatible with vehicles that have no other upgrades to basic "bolt-ons".
Matching this program with the GIAC DSG calibration will give the best results. When using the GIAC engine flash with out the GIAC DSG upgrade the torque gains will be only 25 - 30 Ft-Lbs over OEM.
OEM Horsepower
and Torque
138 HP  236 Ft-Lbs
GIAC Pump Mode*
165 HP  315 Ft-Lbs
GIAC Race Mode**


HP and Torque figures are average engine estimates derived from wheel power and acceleration testing.
* 91 (r+m)/2 or 95 RON fuel compatible. 93 (r+m)/2 or 98 RON equivalent fuel for optimum results.
** 104 RON fuel compatible. 109 RON equivalent fuel for optimum results.
Dyno Plots
seat Leon ® ( MK2 2005 - 2011 ) - GIAC Stage_1_Plus dynoplot
seat Leon ® ( MK2 2005 - 2011 ) - GIAC Stage_1_Plus dynoplot
Supported ECUs
03L906018E
03L906018AT
03L906018FQ
03L906018LJ
03L906018QH
03L906019AN
03L906019CL
03L906019CM
03L906019CT
03L906019DA
03L906019DB
03L906019EE
03L906019EH
03L906019FL
03L906019
03L906019HC


Transmission Controllers


Info
GIAC's DSG software for the 140PS and 150PS 2.0TDI offers improved shift speed and smoothness, increased torque limiters and in some cases launch control. The GIAC DSG flash is required to get the full benefit of a GIAC engine calibration, as the OEM DSG program is designed to significantly limit torque transferred to the wheels.
Supported ECUs
02E300058M_3524
